Refreshing xClass Field on Form in Field Event OnChange
So I wrote a client side method so when you change the Classification of a part, it selects a matching xClassification. This part is working, except the UI isn't updating with the selection of the xClass, so its prompting me to enter the required properties for my xClass, but I can't see them. How do I get the xClass field on my form to update so that it displays my new selection? Several examples used aras.uiReShowItemEx() but that pulls from the database, but the xClass selection has not be saved to the Part yet... so its blank. It looks like form.populate() is the right idea because its not pulling from memory but everything I try returns form as null...
bryan-riley
3 months ago Place Development
188Views
0likes
3Comments
Can Assembly has different version of BOM?
Hi, We have following scenario, I have one Part assembly, and has 8 Part BOM as shown below. Can we change the Part BOM to older revision that has state "Released". Note: Here Part assembly is in "Released" state and locked for updating. We can promote assembly to "Manual Change" state but related Part BOM got unlocked and got synced to their latest revision, which we do not want. Is there any way were we can change the few property of the Part assembly without unlocking the Part BOM? (We do not want to sync the revision of PART BOM if it has higher revisions.) Thanks in Advance !!
depk_topsoe_com
3 months ago Place Getting Started
118Views
0likes
2Comments
How to get comment value during Item promotion via Lifecycle
Hi Community, I have a short question regarding the 'Get Comment' feature that we can use in LIfeCycles. When we choose "Get Comment = 1" for a LifeCycle Transition, the end user will be asked with a dialog to add some notes why the lifecycle was changed. Is it possible to get this comment value from Pre or Post or may be some other way? Thanks a alot.
gaurav_gau_sharma
4 months ago Place Development
56Views
0likes
1Comment
How can I trigger the classification to update and change forms from a different property?
Hi Aras Community, I have a use case where my classification is technically controlling two things. What type of workflow they are on and what kind of form they see with the ability to switch the different kinds of forms. I'm trying to prevent mistakes from happening by providing 2 drop downs one that shows the workflow type and another that offers the form options. On selecting the form options, I need to update the classification and have the form change to the proper form. My current code updates the classification but does not execute whatever code causes the form to change on the classification update the way it does if you type it in or use the classification dialog box. Below is the code I'm starting with I don't know if there may be an API I can call that does this change or if there is a way to refresh the iframe that I'm not aware of. Any help is greatly appreciated. var inn = top.aras.newIOMInnovator(); var formtype = document.all("form_type").value; var worktype = document.all("workflow_purpose").value; var classification = ""; switch(worktype){ case "New Work": if(formtype = "form1"){ classification = "form1/Create New"; }else{ classification = formtype+"/"+worktype; } break; case "Other Work": if(formtype = "form2"){ classification = "form2/Other Work"; }else{ classification = formtype+"/"+worktype; } break; } window.handleItemChange("classification",classification); window.handleItemChange("form_type", formtype); return this;
Solved
phinnix
4 months ago Place Development
351Views
0likes
2Comments
Getting Item id from custom context method on Tree Grid View
Hi, I have two new ItemTypes that i use to add project activities and tasks to the Part ItemType like this: I have created a new query definition and tree grid view to display the structure on a new tab on the Part: I have also created a custom context menu item with corresponsing method that is intended to set the Done property on the selected task. The issue i am struggeling with is that i cant get the Item id of the selected row. var taskItem = aras.newIOMItem('Task', 'edit'); var tgvContext = inArgs.contextParams.tgvContext; var tgvGrid = tgvContext.grid; var tgvGridData = tgvContext.getGridData() var dataObject = tgvGridData.focus[0].row.cells[0].data; aras.AlertError("Result: " + dataObject); as shown from the output i get "INVALID_ID_VALUE" Hope somebody can assist here.
BerntOve
4 months ago Place Community Lounge
1.2KViews
0likes
5Comments
Pass a property into a window.open() command
This seems simple, but I'm struggling with it. I've got a button added to a toolbar that I want to open an external URL with. The URL is saved as a property against the item. Have tied a method to the button and it's a Client-side javascript. Problem I'm getting is that the command window.open doesn't recognize the variable or const. I've tried various forms of this including nesting the getProperty into the window.open, but nothing seems to work. I have some HTML that works on the form, but I'd really like this as a button in the toolbar instead. Here's the working code in the HTML form: <a id="newlink2" href="#" onclick="return showURL2();" target="_blank" style="color: #3668B1;text-decoration: underline">Open 3D Model</a> <script> function showURL2() { debugger; var description2 = document.thisItem.getProperty("_forgemodelurl"); if (description2) { document.getElementById("newlink2").href = description2; } else { top.aras.AlertError("Please Enter the Forge 3D Link with value."); return false; } }; </script>
Solved
jeff_stroh
4 months ago Place Development
2.8KViews
0likes
3Comments
Innovator is not defined Client Side Error
I've got a very simple method that creates a new PR from a button on a TGV. This worked perfectly in V12, but is not working in our V15 instance. Any help would be greatly appreciated! The error message is: The method 'create_PR_from_tgv' failed. Innovator is not defined Client Side Error The code is below: var inn = new Innovator(); var pr = inn.newItem("PR","add"); pr.setProperty("parent", thisItem.getID()); top.aras.uiShowItemEx(pr.node, "tab view", true, true);
jeff_stroh
4 months ago Place Development
4.2KViews
0likes
8Comments
Using a method to update a team, doesn't seem to iterate beyond the first
Hi Community. I am setting up a method to assign a user to multiple teams based on a form. The issue I am having is that it seems to only apply the user to the first team I select (using a multi-value list). Essentially, I am defining on the form - The user identity to add The name of the team to add them to Their team role and regions they are responsible for Code is below: Innovator inn = this.getInnovator(); //Get the form used to make the GPR change selections Item qryGprItem = this.newItem(this.getAttribute("type"), "a_GetControlledItem"); qryGprItem.setID(this.getID()); Item gprItem = qryGprItem.apply(); string[] prodCats = gprItem.getProperty("a_add_to_prodcat").Split(','); string regions = gprItem.getProperty("a_add_to_region"); string gprAction = gprItem.getProperty("a_add_or_remove"); foreach (string prodCatValue in prodCats) { string prodCat = prodCatValue; Item qryTeamItem = inn.newItem("Team", "get"); qryTeamItem.setProperty("name", prodCat); Item teamItem = qryTeamItem.apply(); if (gprAction == "Add") { Item teamMember = inn.newItem("Team Identity", "add"); teamMember.setPropertyItem("source_id", teamItem); teamMember.setPropertyItem("related_id", gprItem.getPropertyItem("a_user_to_modify")); teamMember.setProperty("a_team_region", regions); teamMember.setPropertyItem("team_role", gprItem.getPropertyItem("a_gpr_role")); return teamMember.apply(); } if (gprAction == "Remove") { } } return this;
Solved
Morgan
4 months ago Place Development
2.3KViews
0likes
2Comments
What is the correct way to parse DateTime on a server side onAfterGet event?
Hi everyone. I'm currently trying to evaluate the current date and a date property however, when I try do parse the string provided by getProperty, it gives me the error: String was not recognized as a valid DateTime. I can confirm the property is of the Type: Date and Pattern: Short Date. My relevant code: for (int i = 0; i < this.getItemCount(); i++) { Item thisItem = this.getItemByIndex(i); string dateStr1 = thisItem.getProperty("_calibrated_next",""); DateTime date1 = DateTime.Parse(dateStr1); } The only thing that I can think of that may cause this error is the date format conversion when localized from neutral UTC, but I couldn't find much in the Aras documentation related to this. Thanks
Solved
RaptureLazarus
4 months ago Place Development
4KViews
0likes
4Comments
Client side Form function and script not evaluating correctly.
Good day all. TL;DR: I am having trouble getting an onLoad method to reliably print an evaluated value to a field. The form is as follows: Stock message contains: <span id='stock_msg'></span> I have a javascript onLoad method that compares the minimum and current stock: // Create min and current stock variables var minStock = document.thisItem.getProperty("_minimum_stock"); var currStock = document.thisItem.getProperty("_current_stock"); // Bring in HTML field span var field = document.getElementById("stock_msg"); // Create stockMsgValue variable var stockMsgValue = null; // if current stock is less than or equals to minimum stock if(currStock <= minStock) { stockMsgValue = "<p style='color: red'>Not enough Stock!</p>"; } else { stockMsgValue = "<p style='color: green'>Stock levels look good</p>"; } // Write to HTML field span field.innerHTML += stockMsgValue; I did something similar with Stock message 2, but included the javascript in the HTML field directly: <div id="Message"></div> <div id="min"></div> <div id="curr"></div> <script> var divText = document.getElementById("Message"); var divCurr = document.getElementById("curr"); var divMin = document.getElementById("min"); var currStock = document.thisItem.getProperty("_current_stock"); var minStock = document.thisItem.getProperty("_minimum_stock"); if(currStock <= minStock ) { var textVal = "<span style='color: red';>Insufficient</span>"; } else { var textVal = "<span style='color: green';>Sufficient</span>"; } divText.innerHTML += textVal; divMin.innerHTML += "Minimum stock: " +minStock; divCurr.innerHTML += "Current stock: " + currStock; </script> The problem is that it works for a little bit, and then the evaluation does not reflect the correct values. Some examples: Any ideas? Thanks
Solved
RaptureLazarus
4 months ago Place Development
5.7KViews
0likes
8Comments
