How do you import Excel BOM data into Aras Innovator open version?
Hello, I currently use the open, free version of Aras Innovator and am having difficulty figuring out how to store BOM data within the tool. I have seen from other posts that subscribers have access to a direct import functionality and also some kind of batch loader. For the latest free version of ARAS, what are the exact steps to import an excel file containing BOM data into Aras? Any help would be greatly appreciated.6KViews1like7CommentsRESTFul API Delete Method Error 405
I tried to delete ItemType by following the Document about RESTful API in Aras. For example, PostMan was called as below (DELETE) localhost/.../exItemType ('abcde') If you call it url A 405.0 - Method Not Allowed error message is returned. Additionally, I tried to remove the RelationshipShip for itemType, but the same error occurred. Relationship remove was also carried out according to Document's method. For example, PostMan was called as below (DELETE) localhost/.../$ref This also returns an error of 405. How can I use RESTful to remove itemType?0Views0likes2CommentsUpgrading Aras Innovator Version 11 Service Pack Versions
Hi all, We are currently on Aras Innovator Version 11.0 SP9. From my understanding, the latest service pack available for Version 11.0 is SP15. My question is, is it still possible to upgrade from SP9 to SP15? If so, what would be the effort/duration required to do so? Is it a complicated procedure or a relatively simple one? Thanks!0Views0likes1CommentFeature licenses error when activate
We are using a stand-alone server currently until we get ARAS fully stood up, then we will go live. We received the feature license keys and went to activate feature key but we keep receiving the pictured error below. It also pops up upon entering our database. Has anyone seen the below error before?1.9KViews0likes4CommentsError loading Recipient Relationship tab of DCO and EDR change management giving error when refreshing the CM tab
Hi, when opening ECO/EDR the first time there is no Proplem opening the Recipients Relationship tap, but when opening another a second ECO/EDR the recipients Relationship tap doesnt load. when trying to refresh the item it gives an error message 'The method "cui_ivicb_refresh_click" failed.' only when changing to another relationship tap i can click on refresh with no error, then if changed back to Recipients the recipients list will appear. this issue was not there before the updates were done on .NET code. please help me if you have an idea about this problem and how to approach it. thanks0Views0likes1CommentTrouble Exporting HTML Table to Excel in Aras Innovator Custom Button
Hello everyone, I've been working on a custom button within the search tab for parts in Aras Innovator. The goal is to export a list of specific parts and their properties through a query and display them in an HTML table. Here's a snippet of the code I'm using to convert the HTML table to Excel and download the Excel file: [embed:dc8ab71f-3b98-42d9-b0f6-e21e02a0f8e2:4ac1465e-c931-489c-a19e-bb242bc1c5f6:type=javascript&text=var%20htmlCode%20%3D%60%0A%3Chtml%3E%0A%3Chead%3E%0A%3Cmeta%20http-equiv%3D%27Content-Type%27%20content%3D%27text%2Fhtml%3B%20charset%3Dutf-8%27%20%2F%3E%0A%3Cscript%20src%3D%27https%3A%2F%2Fcdnjs.cloudflare.com%2Fajax%2Flibs%2Fxlsx%2F0.16.9%2Fxlsx.full.min.js%27%3E%3C%2Fscript%3E%0A%3Cscript%20src%3D%27https%3A%2F%2Fcdnjs.cloudflare.com%2Fajax%2Flibs%2FFileSaver.js%2F2.0.5%2FFileSaver.min.js%27%3E%3C%2Fscript%3E%0A%3Cscript%3E%0Afunction%20substituteTableToExcel%28%29%7B%0Avar%20table%20%3D%20document.getElementById%28%27all_Parts_AML%27%29%3B%0Avar%20sheet_name%20%3D%20%27ALL_Parts_AML%27%3B%0Avar%20workbook%20%3D%20XLSX.utils.table_to_book%28table%2C%20%7Bsheet%3A%20sheet_name%2C%20cellStyles%3A%20true%7D%29%3B%0Avar%20wbout%20%3D%20XLSX.write%28workbook%2C%20%7B%20bookType%3A%20%27xlsx%27%2C%20bookSST%3A%20true%2C%20type%3A%20%27array%27%2C%20cellStyles%3A%20true%20%7D%29%3B%0AsaveAs%28new%20Blob%28%5Bwbout%5D%2C%20%7B%20type%3A%20%27application%2Foctet-stream%27%20%7D%29%2C%20%27ALL_Parts_AML.xlsx%27%29%3B%0A%7D%0Adocument.addEventListener%28%27DOMContentLoaded%27%2C%20function%28%29%20%7B%0AsubstituteTableToExcel%28%29%3B%0A%7D%29%3B%0A%3C%2Fscript%3E%0A%3Clink%20rel%3D%27stylesheet%27%20type%3D%27text%2Fcss%27%20href%3D%27styles.css%27%3E%0A%3C%2Fhead%3E%0A%3Cbody%3E%0A%24%7BexcelTable%7D%0A%3C%2Fbody%3E%0A%3C%2Fhtml%3E%60%3B] return htmlCode; I'm encountering issues with the export functionality. When I click the custom button, the HTML table is generated correctly, but the Excel file download doesn't seem to work. Could someone kindly review the code snippet above and provide any insights or suggestions on how to troubleshoot and resolve this issue? I would greatly appreciate it. Thank you in advance! Version 12.0 SP8Solved0Views0likes2CommentsComments after return in Client Method leads to 'event handler' error
Hi community, I discovered a strange behavior in Innovator 12. Let´s assume we have a regular Form with a button that uses the following onClick event: alert("This is just a test button event"); return; // Todo for later: add additional validation This Method will lead to the following error Message: 'Event handler' failed with the message: ReferenceError: func $ BD472BC271CA48E88DE6CB0C7E3CED75 $ _onclick2 is not defined I noticed that the Method works fine, as soon as I remove the comment behind the return. Of course in normal code we most of the time do not have any additional comments after the final return. But when creating new Methods, I often place later used code at the bottom so I can take care for it later. Comments after the return statement were never any problem in Innovator 11. It took me quite a few days until I finally discovered why certain parts of my new code never worked. Is there an explanation for this new behavior? Are there any other new design rules to consider when programming in Innovator 12? Would be happy about any hints to avoid similar effects! Thanks! AngelaSolved13KViews0likes10CommentsWill the upcoming Innovator 12 edit concept lead to tons of nonsense revisions?
Hi, I think this one is a good topic for a Community discussion. I have seen the Aras Innovator 12 demo at ACE Europe 2018. One upcoming UX enhancement is a simplified way to edit an Item. I really like the new concept, but I wonder if it will eliminate the ability to overwrite existing generations when using the automatic revision mode. Let´s assume we have an Item with Versioning Disciple “Automatic”. Typical use cases are Methods, Workflows but maybe also the standard Parts or Documents. As long as you have locked an Item, the existing Item generation will be overwritten while editing. The current “Lock” helps to prevent that every little change leads to a new Item revision. But as far as I have understand the demo, “Lock” will be removed in the upcoming Innovator version. Of course we have the option to choose by our self, if we want to use Automatic or Manuel revision mode. But especially for core ItemTypes, it isn´t wise to change the revision mode. What does the new edit concept mean for the automatic revision mode? Will we now get tons of nonsense revisions? I am already looking forward to your opinion! And I hope Aras will correct me if I got things totally wrong. Best regards! Angela5.5KViews0likes6Comments
