Upload file Rest API using Logic App
I am currently developing a sample project in Azure Logic Apps using the Aras Restful APIs. However while trying to Execute the vault.UploadFile API I am facing the 500 error message: The Rest API Call Details are as follows : { "uri": ".../vault.UploadFile?fileId=EB166A9FF4EE47C8A0DA55252CA140CA", "method": "POST", "headers": { "Authorization": "*sanitized*", "Content-Disposition": "attachment;filename*=utf-8''Hello.txt", "Content-Length": "5", "Content-Range": "bytes 0-4/5", "Content-Type": "application/octet-stream", "transactionid": "0c2c787fce70226029d752c0ba372607" }, "body": "Hello" } For now I am trying to upload a simple text file as seen above. I have verified the url as well as run the same in Postman , ARC and fiddler - and I am able to get it working in all the cases except for via Logic Apps . Please let me know if anyone knows what I am missing here . Thanks
Upload File without creating a new generation
I wish to create an Action for the Document ItemType that 1. Prompts the user to select a file, 2. Uploads the file, and 3. Does not create a new generation of the Document Item. Use Case: A Document, for example at Rev C, are reviewed via the out-of-the-box (OOTB) Document Change Object. Prior to the Release step, a PDF file is generated and submitted to the customer. The workflow is then completed, setting the state of the Document as Released. The PDF is sent to the customer for approval. And a new revision, Rev D, of the Document is started using subsequent DCO. Not a problem. The customer returns a wet-ink or digital signed PDF file of the Rev C of the Document. This version of the PDF is to be included in the the latest generation of Rev C, which most probably will have been updated by Rev D and subsequent generations. It is not appropriate to add the signed PDF to Rev D or later iteration. This process is possible using AML, by 1. Determine the ID of the latest generation of Rev C of the document. 2. Using admin, drag and drop the file into the file vault. 3. Get the ID of the file, after it has been uploaded, and 4. Using AML <AML> <Item type='Document File' action='add'> <source_id>id of the document at the correct generation</source_id> <related_id>id of the uploaded file </related_id> </Item> </AML> Can the above sequence be done using an Action, a Form with a File Item field or some other method?
Uploading CADdocs with Relationships from local PC to ARAS
Hi All, looking to create a method to allow me to upload CADdocs into Aras, from my local computer, without needing to use a CAD Connector. I am new to developing for Aras and could use some pointers. Does anyone have any ideas or could lead me down the right path to get something started. I'm envisioning a form where I select the top-level assembly and its children from a folder on my desktop and upload them into Aras. Any help or tips are appreciated!
Upload a file as attachment to document Item
Hi, I would like to know is it possible to load a doc or docx file to aras using data loader. I am using data loader which load the document(Item) from excel file. so is it possible to load the file(attachment) load with the parent Item (in Document File Relationship)i.e. wih Document. Thanks.Does ARAS server need access to the file for Item.attachPhysicalFile to work?
We are using a cloud version of ARAS, and I am trying to attach a physical CAD file to an item. But I am receiving the exception: Item is not of type 'File'. I have verified the existence of the file, and the path is in UNC format, so I am wondering if the server needs physical access to the file for verification. at Aras.IOM.Item.CheckThatTypeOfItemIsFile() in d:\Builds\Innovator.Builds\6296-Innovator-RELS11-0-SP5\Innovator\CompilableCode\IOM.NET\Item.common.cs:line 5359 at Aras.IOM.Item.attachPhysicalFileInternal(String filePath, String vaultServerId) in d:\Builds\Innovator.Builds\6296-Innovator-RELS11-0-SP5\Innovator\CompilableCode\IOM.NET\Item.common.cs:line 5234 at Aras.IOM.Item.attachPhysicalFile(String filePath) in d:\Builds\Innovator.Builds\6296-Innovator-RELS11-0-SP5\Innovator\CompilableCode\IOM.NET\Item.common.cs:line 5173 at ARASImport.frmImportPLM.UploadPartDocuments(Item part) in c:\code\frmImportPLM.cs:line 1504
Upload Files with AML - does it still work this way?
Hi Community, in many forum posts samples are shown how to upload files via AML. Typical one: <Item type='Document' action='add'> <item_number>uploadtest</item_number> <name>myName</name> <description>myDescription</description> <Relationships> <Item type='Document File' action='add'> <related_id> <Item type='File' action='add'> <actual_filename>c:\temp\uploadtest.txt</actual_filename> <filename>uploadtest.txt</filename> <Relationships> <Item type='Located' action='add'> <related_id>67BBB9204FE84A8981ED8313049BA06C</related_id> </Item> </Relationships> </Item> </related_id> </Item> </Relationships> </Item> I remember that I was able to use this script successfully in the past. But in Innovator 12 it doesn´t seem to work anymore. Does anyone know if we need a different approach now? Thanks and best regards! AngelaHow to batch download and upload files?
Under Documents, Type= Setup Sheet, State = Released, are documents that are in excel and they have to be converted to pdf I guess the first the step woudl be to get the meta data, Document name, ID, Related Files, and File ID. Then loop through this file to download them. But then what would the path be to download this. How do I go about this? Thanks!!
